2022 new arrival sound proof sash vertical opening double-hung windows for home
1.Product Introduction
1.Aluminum alloy hung windows are made of aluminum alloy building profiles,and the window is divided into non-thermal break aluminum hung windows and thermal break aluminum alloy hung windows.
2.Product Details
| Profiles | Series | 1. 6063-T5 high quality thermal break aluminium profiles 2. 6063-T5 high quality non-thermal break aluminium profiles Commonly used series:65/80mm: 70series max-glass-thickness:22mm |
| | Thickness | 1.4mm |
| | color | Brown\ dark grey\light grey\ black\star black,etc. |
| Glass | Types | Low-e glass\frosted glazing\ grey/blue/green tinted glass,etc. 1.Single:3mm~12mm 2. Double: 5mm 6A 5mm/5mm 9A 5mm/6mm 9A 6mm, etc. 3.Triple: 5mm 6A 5mm 6A 5mm and others 4.Tinted/Reflected/Frosted Glass (Tempered Glass) |
| | Thickness | 4-19mm |
| | color | clear/super clear/ tinted blue/green/coffee brown/gray |
| Hardware | Brand:Germany brand (Siegenia /Roto )\Australia brand\China brand Aluminum alloy hung window: Handle lock+transmission rod+hinge+limit stopper+EPDM sealing strip+invisible screen |
| Mesh | Stainless steel security mesh\Aluminum security mesh Fiberglass flyscreen\Retractable flyscreen |
| Finish | Powder coating \ Anodized \ Electrophoresis \ Wood grain |
| Advantages | 1. Water-proof & Air-proof 2. Anti-aging 3. Space Saving 4. Sound Insulation & Heat Insulation 5. Opening Smoothly 6. Dust resistance 7. Good air mobility, good daylighting 8. Easy maintenance 9. Good Combustion-retarding Performance |
3.Profile Details
| Profiles | 1.Non-thermal break aluminum profiles
2.Thermal break aluminum alloy profiles 3. Frame: 6063/6065 and different aluminum profiles produced by our own factory |
| | Non-thermal break aluminum hung window 1.Common series:65/80mm 2. the biggest glass thickness:22mm 3.The profile thickness: 1.4mm |
| | Thermal break aluminum hung window 1.Common series: 80mm 2. the biggest glass thickness:22mm 3. The profile thickness: 1.4mm |
| | Color: Silver oxide, electrophoretic champagne,spraying white/dark grey/ light grey/coffice/brown/red/black, wood grain,others,customized |
| Surface Treatment | 1.Spraying 2.Anodizing 3.Electrophoresis 4.Wood grain transfer 5.Coating |
4.Glass Details
| Glass | Types | Low-e glass\frosted glazing\ grey/blue/green tinted glass,etc. 1. Double tempered glazing:5+12A+5,6+12A+6 2. Single tempered d glazing:6,8,10,12... 3. Laminated glass:6.38,10.76,10.38... |
| | Thickness | 3mm/4mm/5mm/6mm/8mm/10mm/12mm/6.38mm/8.38mm /10.38mm/10.76mm/12.76mm/11.14mm/4mm+6air+4mm/5mm+6air+5mm /5mm+9air+5mm/5mm+12air+5mm/6mm+6air+6mm /6mm+9air+6mm/6mm+12air+6mm |
| | color | clear/super clear/ tinted blue/green/coffee brown/gray |
5.Hardware Accessories
6.Product Parameters
| Item | Parameter | Item | Parameter |
| K/U (insulation) | <1.1 | Glass thickness/mm | 3-30 |
| Airtightness/m3/(m2.h) | ≤0.5 | Profile Width/mm | 50-135 |
| Watertighness/Pa | ≥700 | Transmittance | 60%-98% up to glass type |
7.Processing Procedure
Aluminum top-hung window: blanking - assembly angle - glue - EPDM sealing strip - weather strip -installing glass bead and glass -installing hinge - installing handle lock and transmission rod / ”7” handle lock
8.Quality Control
Quality inspection:
1. Raw material quality testing: the color, thickness and strength of profiles will be checked after the profiles arrive at the factory. After the glass to the factory, the color and thickness of the glass will be checked again, and the sealing performance of hollow glass will be checked. Hardware color will be checked and tests how well the hardware works.
2. In the production process, there will be special quality inspectors to check each process of production.
3. After the product is finished, the group corner, sealing, size, use effect and so on will be tested
9.Product Package
Product packaging:
1. Stretch film packaging
2. 5 carton packaging
3. Fumigation-free wooden frame packaging
4. Packed in wooden cases with fully enclosed and fumigation-free plywood.
Different packing methods can be applied to FCL and LCL.
10.Project Case
11.Customer Feedback
12.Company Profile
Ace Window Doors USAis a collection of design, production, domestic engineering, export trade, foreign installation in one of the large doors and Windows construction engineering enterprises, with 11 years of experience in doors and Windows export.
We do excellent in assisting customers to design,manufacture and install windows and doors for their house,office, villa, factory and Airport,etc.After sales, We will always provide good service, like how to fix hardware and how to install windows and doors.We will gladly evaluate your needs and recommend the arrangement that is best for your requirements.
13.FAQ
Q1: All these doors and windows come with frames to mount on walls?
A: Yes, all doors and windows are finished with frames and hardware together, you can just install to the wall.
Q2: The glass will be broken after I received the goods?
A: The glass would be broken only because suffering from the impact force, but it won’t break itself.
Q3: UPVC/PVC and aluminum profile, which is better?
A: It cannot say which one is better, they have both advantages.UPVC/PVC is good performance for sound and heat insulation.Aluminum is harder and strong for security. Aluminum also have thermal break profile to insulate heat.
Q4: What are your payment terms?
A: Usually we accept T/T, 30% down payment and pay off balanced payment before shipping. If you want to pay by L/C or west union we also can accept now.
Q5: How about your delivery time?
A: Delivery time depends on your order quantity, some special color need long time get material.
But usually the delivery time is around 10-15days for common color and profile.
Q6. What about your packages ?
A. Inner EPE paper packing, exterior with wooden frame crate box.We have been exporting lots of products overseas, no any clients make any complains on our packages.
